Features and benefits
| Availability | Optional |
| Remote Control | Full function wireless |
| Reach | 23 ft (7 m) |
| Hose diameter | 8 in (3.14 cm) |
| Controls | Full-function wireless remote (optional belly pack or handheld) |
| Gauges | Electronic display with 7-in LCD screen |
| Hot box | Dynablast - 420K BTU |
| Cold weather options | Heated cabinets, water lines and valves |
| Vibrator | Spoil tank vibrator |
| Onboard air compressor | 180 cfm (5.10 cu-m/min), 110 psi (7.6 bar) |
| Water Pump | 19.4 gpm (72.7 L/min) |
| Spoil tank capacity | 12 cu-yd (11 cu-m) |
| Door type | Cam-over hydraulic |
| Tank Lift Type | Telescopic cylinder |
| Compatibility | 12-cu-yd spoil tank option |
| Length | 33.4 ft (10 m) |
| Width | 98 in (249 cm) |
| Height | 12.25 ft (4 m) with boom |
| Empty weight | 40,000 lb (18,144 kg) estimated |
| Gross Vehicle Weight Rating (GVWR) | 86,000 lb (39,009 kg) |
| Truck model | Kenworth T880 |
| Engine model | MX-13 |
| Horsepower | 510 hp (380 kW) |
| Transmission | Allison 4500 |
| Compatibility | 12-cu-yd spoil tank option |
| Length | 33.4 ft (10 m) |
| Width | 98 in (10 m) |
| Empty weight | 40,000 lb (18,144 kg) estimated |
| Height | 13.25 ft (4 m) with boom |
| Gross Vehicle Weight Rating (GVWR) | 86,000 lb (39,009 kg) |
| Truck model | Mack Granite |
| Engine model | MP8 |
| Horsepower | 505 hp (377 kW) |
| Transmission | Allison 4500 |
| Type of Filters | 2-micron washable filter |
| Hose length | 23 ft (7 m) |
| Air flow | 6400 cfm (181.2 cubic m/min) |
| Vacuum blower type | Jurop |
| Vacuum | 27 inHg (.91 bar) |
| Number of Tanks | 2 |
| High Pressure Pump | 3000 psi (206.8 bar) |
| High pressure hose length | 100 ft (30.5 m) |
| Low Water Shutoff | Electronic sensor indicators |
| Water capacity | 1200 gal (4542 L) |
| High pressure pump flow rate | 10 gpm (37.9 L/min), optional 19.4 gpm (72.7 L/min) |
